Decreased vascular lesion formation in
mice with inducible endothelial-specific expression of protein kinase Akt
J. Clin. Invest. Yasushi Mukai, et al. 116:334 doi:10.1172/JCI26223 [
Go to this article.]
Figure 3Photomicrographs of ligated mouse carotid arteries. (
A) Photomicrographs of carotid arteries 4 weeks after ligation (H&E staining) in WT, single-Tg (tet-myrAkt),
noninduced EC-Akt Tg, and
induced EC-Akt Tg mice. Arrowheads indicate internal elastic lamina. (
B) Photomicrographs of H&E staining of carotid arteries 4 weeks after ligation in WT and induced EC-Akt Tg mice treated with
L-NAME. Scale bars: 100 μm.
